« Last post by jim ballantyne on Today at 04:12 PM »
Got mine today,excellent book I've been up there quite a few times and it looks like I've only scratched the surface so far.
If you still have the bike apart, a very simple mod, bring out the vacuum lines, I used a stainless steel 1/4 bolt and cut the threads off as a vacuum plug. The photo shows my gauge on the 2015 using 1/4 vacuum couplers , the line for the extension I think is 7/32 , purchased from a auto supply store. One point, usually one throttle body has the adjustment screw all the way in , many times it is cylinder #2. Finding vacuum sync off usually is a indication that the valve clearance is off. When I did my valve shim on the 2015, the sync was bang on, no adjustment needed.
So I mentioned in my other post about a new flash available for 2015-2016 650 Versys, I did that on my ECU, I can say the bike is now superior to both my old 07 and the original 2015 before the flash, since I end up in the below 4000 RPM whenever passing through small towns when riding on the highway, this flash has been worth every penny, as in 2018 I considered getting a different bike, the only thing stopping me was the extensive amount of mods I had already completed on the Versys. I can say this one is now a keeper with the new flash.
Notice the white couplings on the vacuum gauge, the red and yellow tape represent cylinder #1 red & #2 yellow
These lines are wire tied to my Denali split sound balm horn compressor, so minutes and I can check vacuum sync without removing anything.
Lines brought out from formerly capped ports on the TB , red is cylinder #1
Good idea, Mop. Both my 650 V's have come out of the box with t.b.s out of sync. I've had good luck with the CarbTune. Adjustment screws are fiddly to get at, 'tho. I use a small flat blade screw driver that came with my wife's sewing machine.
As for the flat spot. It doesn't exist in N.A. bikes 2008 - 2014. Can't speak for 2015 as it was a new model. Until 2015 N.A. bikes had no O2 sensor.
But all pre 2015s need to be kept spinning above 3000 rpm to avoid jerkiness in stock form. Properly adjusted valves and t.b.s make a noticeable difference.
We buy in pumps and sensors and make everything ourselves either in our own USA workshop or several partner workshops worldwide.
Wow, that's impressive.
You say "We". I thought you were buying stuff in, I didn't appreciate you were making the things.
We give a 10 year materials an manufacturing guarantee on the tower.
Expected life span is 15 years
What component life are you getting?
Thanks InverterMan. So the flat spot is common to the 2015 650 V? As syncing the throttle bodies is a 7,500 mile service task I think I should do it anyway so I'll have a look at the CarbTune Pro.
